제품 특징:

. 802.11n/ac 450Mbps + 1300Mbps 단독형

. N+ 450Mbps/ AC+ 1300Mpbs

. PoE(Powr over Ethernet)지원 LAN 포트

. 다양한 무선 동작 방식: AP/WDS/WDS with AP/Client 방식을 지원함.

. WPA-Personal, WPA-Enterprise, 802.11x보안 지원.

. AP Array

. IEEE 802.11abgn/ac

. 최대 송신 출력: 26dBM@2.4Ghz/5Ghz

안테나 특징:

• 3x19dBi Directional Gain
• Three Polarization in One Case
• Integrated enclosure
• Mounting for Mikrotik 411, 433, 600, series
• Mounting for Ubiquiti Rocket
• High Quality Construction
• Heavy-Duty Mounting Elements
• Easy Elevation and Tilt Adjustment
• Designed for All Weather Operation
• Frequency range 5.1-5.9Ghz
• Gain 3*19dBi
• Polarization V,H,V or H,V,H
• Beam width horizontal 20도
• Beam vidth vertical 20도
• VSWR <2
• Weight about 3kg
• 최대 소비젼력: 9Watts
• 크기: 386*386*81.5mm
• 동작운도: -40 ~  + 80도

안테나 응용:

• 5 GHz Band Wireless LAN
• IEEE 802.11a WLAN Systems
• 802.11n/MIMO standard
• 3x3 MIMO applications
• Nstreme dual configuration
• Point to Point Applications
